HR2811F
1‑1/8'' SDS‑PLUS Rotary Hammer

About ModelFeaturesIncludesSpecsResources & MediaRelated

HR2811F

1‑1/8'' SDS‑PLUS Rotary Hammer

  • POWER: 7.0 AMP motor delivers 0 - 1,100 RPM and 0 - 4,500 BPM for demanding applications
  • PERFORMANCE: 3-mode operation for:“Rotation Only” , “Hammering with Rotation” or “Hammering Only”
  • CONVENIENCE: Built-in L.E.D. light illuminates drilling surface
  • COMFORT: Compact design with padded grip and side handle for increased operator comfort
  • INCLUDES: Side handle, depth gauge and case
1-1/8'' SDS-PLUS Rotary Hammer
OVERVIEW
Makita HR2811F Kit Shot - Thumbnail Makita HR2811F Product Shot - Thumbnail
APPLICATIONS
Makita HR2811F Action Shot 1 - Thumbnail Makita HR2811F Action Shot 2 - Thumbnail Makita HR2811F Action Shot 3 - Thumbnail Makita HR2811F Action Shot 4 - Thumbnail Makita HR2811F Action Shot 5 - Thumbnail
FEATURES
Makita HR2811F Feature Shot (case) - Thumbnail Makita HR2811F Feature Shot (what's in the box) - Thumbnail Makita HR2811F Feature Box with text_Comfort - Thumbnail Makita HR2811F Feature Box with text_Reliability - Thumbnail Makita HR2811F Feature Box with text_Versatility - Thumbnail Makita HR2811F Feature Box with text_Visibility - Thumbnail
RELATED VIDEOS
Makita Rotary Hammer Operation Guide (HR2811F) - Thumbnail

About Model

Model HR2811F is a versatile, high-powered rotary hammer with an L-shape design ideal for horizontal work. The hammer accepts SDS-PLUS bits, and is powered by a 6.7 AMP variable speed motor delivering 2.7 Joules of impact energy. The HR2811F features 3-mode operation for “rotation only”, “hammering with rotation”, or “hammering only” for multiple applications, with 0-1,100 RPM and 0-4,500 BPM. The torque limiting clutch prevents gear damage by automatically disengaging gears if the bit binds. The HR2475 has an LED light for improved illumination of the work surface.

Makita rotary hammers are engineered with the Makita Motor Advantage, which features field core interlocking steel laminations, dual ball bearing armature, and more copper commutator bars. These engineering points-of-difference increase the energy transfer efficiency for more power and longer tool life.

Features

  • Powerful 7.0 AMP motor delivers 2.1 ft.lbs. of impact energy to handle the most demanding applications
  • Vibration-absorbing back handle for operator comfort
  • L.E.D. light illuminates drilling surface for more productivity in low light applications
  • 3-mode operation for "Rotation Only", "Hammering with Rotation" or "Hammering Only"
  • "No hammering when idling" function helps increase tool life
  • Sequential impact timing delivers timed hammering during rotation to minimize overlapping bit impacts for up to 50% faster drilling
  • Torque limiting clutch engineered to prevent gear damage by automatically disengaging gears if the bit binds
  • One-touch sliding chuck for quick bit changes
  • Recessed lock-on button for continuous operation
  • Extended life brushes for more work between service intervals and less downtime
  • Makita Motor Advantage engineered with field core interlocking steel laminations, dual ball bearing armature and more copper commutator bars, increasing energy transfer efficiency for more power and longer tool life

Includes

  • (1) Depth Gauge (324219-0)
  • (1) Plastic Tool Case (824789-4)
  • (1) Side Handle (154842-5)

    • Specs

  • AMPS :7
  • Max. Capacity (concrete drilling) :1-1/8"
  • Optimum Range (concrete drilling) :1/4" - 5/8"
  • Max. Capacity (concrete drilling w/ core bit) :3-1/8"
  • Impact Energy (ft.lbs.) :2.1
  • Impact Energy (Joules) :2.9 J
  • Blows Per Minute (variable speed) :0 - 4,500 BPM
  • No Load Speed (variable speed) :0 - 1,100 RPM
  • Vibration Control :No
  • Vibration (m/s²) :15
  • Overall Length :12-5/8"
  • Cord Length (ft) :8.2'
  • Net Weight :7.7 lbs.
  • Bit Type :Accepts SDS-PLUS
  • Power Type :Corded
  • Bind-Up Control :No
  • Shipping Weight :17.64 lbs.
  • UPC Code :088381-083874

    • Resources & Media

  • Makita HR2811F Instruction Manual
  • HR2811F Parts Breakdown
  • HR2811F Flyer English
